In-ground Light
MD25
MD25
Model : MD25
Name: LED Inground Light
Voltage: DC24V
IP66
IK: 06
Size: L1000*W25*H50mm
Housing Material: Al6063 + Tempered Glass
Beam: 15°/20°/30°/45°/20 40°/110°
CRI >80
SDCM <5
Ambient temperature: Tamin=-20 °C, Tamax=55°C
Luminous efficiency: WHITE 40lm/w,RGBW 15lm/w
RH: 30~80%
Warranty: 3 years
LED Brand
ــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــ
Bridgelux/Cree/Luminus/Sanan/Osram/Lumileds/Hongli...
Driver Brand
ــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــ
Lifud/Eaglerise/Osram/Philip/Coie/Kegu..
Non Dimmable
0-10V Dimmable
DALI Dimmable
Triac Dimmable
Name: LED Inground Light
Voltage: DC24V
IP66
IK: 06
Size: L1000*W25*H50mm
Housing Material: Al6063 + Tempered Glass
Beam: 15°/20°/30°/45°/20 40°/110°
CRI >80
SDCM <5
Ambient temperature: Tamin=-20 °C, Tamax=55°C
Luminous efficiency: WHITE 40lm/w,RGBW 15lm/w
RH: 30~80%
Warranty: 3 years
LED Brand
ــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــ
Bridgelux/Cree/Luminus/Sanan/Osram/Lumileds/Hongli...
Driver Brand
ــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــ
Lifud/Eaglerise/Osram/Philip/Coie/Kegu..
Non Dimmable
0-10V Dimmable
DALI Dimmable
Triac Dimmable
| Item No | Power | Color | LED Qty | Control method |
| MD25W48D2 | 12W | White | 48*0.25W | ON/OFF |
| MD25F48D2 | 15W | RGBW | 48*0.3W | DMX512 |
| MD25MW60D2 | 15W | White | 60*0.25W | ON/OFF |
| MD25MF60D2 | 18W | RGBW | 60*0.3W | DMX512 |
Features and Benefits
