TGF405
TGF405
LED Flood Light
TGF405
Model : TGF405
Name: LED Flood Light
Voltage: AC110~240V
IP66
IK: 06
Size: L404*W196*H322mm
Housing Material: ADC12+ Tempered Glass
Beam: 10°/30°/45°/15*25°/20*45°/10*60°
CRI >80
SDCM <5
Ambient temperature: Tamin=-20 °C, Tamax=55
Luminous efficiency: WHITE 80lm/w,RGBW 40lm/w
RH: 30~80%
Warranty: 3 years


LED Brand
ــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــ
Bridgelux/Cree/Luminus/Sanan/Osram/Lumileds/Hongli...


Driver Brand
ــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــ
Lifud/Eaglerise/Osram/Philip/Coie/Kegu..
Non Dimmable
0-10V Dimmable
DALI Dimmable
Triac Dimmable
Item No         Power  ColorLED QtyControl method
TGF405W60A420W White60*2W ON/OFF
TGF405F60A4150WRGBW 60*2.5WDMX512
